Brigade Essential Camera, IP67 White Boxed (PAL) VBV-620C

Product Description: Brigade Essential Camera, IP67 White Boxed (PAL) VBV-620C

Part NO: 3683C | Model No VBV-620C

Brigade Essential Camera, IP67 White Boxed (PAL)

• Camera Viewing angle H 81 x V 59 x D 160deg
• IP67
• Camera Size W 65 x H 59 x D 55mm
• Normal view
• Operating temperature: -10 to +70°C
• PICK-UP DEVICE Pixel Plus CMOS
• TV SYSTEM PAL/NTSC
• PICTURE ELEMENTS 720(H) x 480(V)
• SENSING AREA 5.59mm x 4.68mm
• IMAGE SIZE 1/3″
• SYNCHRONISATION INTERNAL
• HORIZONTAL RESOLUTION TV LINES 500 PAL / 350 NTSC
• REQUIRED ILLUMINATION 0 LUX minimum
• POWER SUPPLY 12 Vdc
• POWER CONSUMPTION 1.2W (AT 12Vdc)
• CURRENT CONSUMPTION 100mA ± 10mA
• LENS ANGLE PAL 109.5°(D), 82°(H), 67.5°(V)º ±5°
• LENS ANGLE NTSC 112°(D), 87º(H), 65º(V) ±5°
• OPERATING TEMPERATURE -30 – +70ºC / -22 – +158ºF
• WEIGHT 280g

VBV-620C
