ACV1 Series Panel/Dash Manual Air Control Valves (6mm Port size)

Product Description: ACV1 Series Panel/Dash Manual Air Control Valves (6mm Port size)

ACV1 Series Panel/Dash Manual Air Control Valves (6mm Port size)

Panel/dash mounted manually operated 4/2 directional control switch for the operation of single and double acting cylinders.

These valves have 6mm or 1/4” Push-in Fitting ports and come as standard with a pneumatic or electric reset facility and control knob indicator as a visual notification that the valve
has been operated.

Key Features
– Compact
– Non-corrosive
– Indicator Band
– Push-in Fittings
– Ergonomic Actuator
– Safety Interlock Port
– 6mm or 1/4” Tubing Versions
Typical Applications-Mobile
– PTO Actuation (Power Take Off)
– Bottom Loading Tanker Controls
– Construction Equipment
– Lift Gates
– Specialty Truck Equipment
– Cement Mixers
– Fire Trucks
Industrial
– Emergency Shut Down Systems
– Pneumatic Control Panels
– Air Compressor Controls
– Test Panels / Benches
– Agricultural Equipment
– Applications for manual operation
